Multifunctional 400mm Slant Bed CNC Lathe 4000RPM Shock Resistant

Name: Multifunctional 400mm Slant Bed CNC Lathe 4000RPM Shock Resistant
Brand: Li Zhun
Price: 1 USD

Wholesale Multifunctional 400mm Slant Bed CNC Lathe 4000RPM Shock Resistant from china suppliers

Brand Name : Li Zhun

Model Number : CK46

Place of Origin : China

MOQ : 1

Payment Terms : T/T

Supply Ability : 10000 per year

Delivery Time : 15-30 work days

Packaging Details : Wooden Box

Certification : SGS

Product Name : CK 46 Slant Bed CNC Lathe

Condition : New

Warranty : 1 Year

Weight : 2600kg

Spindle Speed : 4000rpm

Spindle Turning Diameter : 400 mm

Contact Now

High Precision CK 46 Slant Bed CNC Lathe Hard Guideway High Rigidity

The new CK 46 Slant Bed CNC Lathe inherits the performance and structure advantages of traditional CK models, and have been greatly improved in machining accuracy, reliability, shock resistance and function. The new appearance and control panel make the ease of use of the machine has been significantly improved, greatly improving the work efficiency.

Main Features:

The failure rate is extremely low
The weight of the machine has increased compared with the old model
High speed and high precision, work efficiency is improved
Water proofing property is strong
Easy to operate

Main Technical Parameters

Specification		CK46
X/Y/Z AXIS TRAVEL	mm	910*310
Spindle Turning Diameter	mm	400
Spindle bore	mm	￠56
Spindle Speed	rpm	4000	Taiwan Dianya/Tongfu
Spindle Motor Power	kw	5.5	Keteng/VEICHI
X/Z RAPID FEED SPEED	mm/min	26000/26000	Adjustable 20 m to 30 m
Axial drive/motor power	kw	1.3	Deaour/VEICHI
Spindle Specification	Set	A2-5	Taiwan Dianya/Tongfu
Tools Magazine Capacity	T	7 (Center 50 mm high)
Tools Size	mm	20*20	Drilling ER20
Clamping Size	Set	46#	Draw bar + 46 Spindle nose + hydraulic chuck
Screw Configuration	mm	3210	Taiwan SHAC/ PMI C3
Guideway Configuration	mm	X30Z30	Taiwan SHAC/ PMI(x30mm/z30mm)
Repeated Positioning Accuracy	mm	±0.005
Dimensions	mm	200018001700
Weight	kg	2600	35 degree cast bed + steel structure base

Product Gallery

Multifunctional 400mm Slant Bed CNC Lathe 4000RPM Shock Resistant
